Equipment Features
The main material for aluminum alloy curtain wall, window material cutting, and can also be used for plastic profile cutting.
The use of carbide saw blades, diameter up to 500 dia, line of high speed, high precision machining.
Right heads feeding adopts pitch ball screw-lead motion,with high accurate driving,locating and smooth working.
This machine uses the numerical control technology, profiles of different specifications can be completed automatically under the expected size.
Machine during operation, two saw blade can cut, can separate cutting.
The saw head can be set to 45 degrees and 90 degrees need angle.
The blade from the bottom to the top, sawing profile is more safe and reliable, and the
cutting height and cutting width are large. Input power:5.9Kw
Power supply:380V/50Hz
Air pressure:0.6~0.8MPa
Motor rotary speed:2800r/min
Saw Blade specification: Φ500×Φ30
Cutting angle:90°、45°
Cutting length:400~4500mm
Cutting width×height: 235×135/300×135mm
Overall dimension:5750×1300×1500mm
