Glazing Bead Cutting Saw
SYJW-1800

Glazing

Product description
The machine applies to processing glass bead.
It adopts two saw blades which cut off and chamfer angle for glass bead at same time.
The machine motor is horizontally fixed.
It has characteristics of easy operation, stability, and high efficiency.
Technical parameters
Input power：2.2Kw
Power supply：380V/50Hz
Air pressure：0.5-0.8MPa
Air consumption：20L/min
Motor rotary speed：2800r/min
Cutting height： 33mm
Cutting width： 100mm
Cutting length： 320-1800mm
Overall dimension： 1800×1380×1300mm
