Features:
Milling all kinds of water slots and air pressure balance groove.
Full design with high rigidity, processing beautiful water slot, high appearance quality.
Automatic cutter changer on the under head, one time clamp to finish water slots processing.
High efficiency, suitable for mass production.
Special feeding system, need no special maintenance, high milling quality.
Easily adjustment for the cutter location to meet different kinds of profiles.
Water slot milling length adjustable within 100mm, wide adaptability.
Adopt linear bearing motion to ensure the processing presion. Input Power: 1.14Kw
Power supply: 220V/50HZ
Air pressure: 0.5-0.8Mpa
Air Consumption: 20L/Min
Motor rotary speed: 25000r/min
Cutter Diameter: Φ5 Φ4mm
Slot Depth: 30mm
Slot Length: 30-60mm
Overall Dimension: 950x1000x1800mm
