Features:
Automatically distinguish the coating side of coated glass and low-E glass.
PLC control system with touch screen operation.
Machine work and fault dynamic display.
Outside assembly lines can produce standard double layer IG and three layers IG.
Lines are available for both of inside and outside panel press, which can produce stepped IG, standard double layer IG and three layers IG (optional).
Designed for curtain wall glass, double layer IG and three layer IG glass.
IG press design-gear and chain synchronous device driven by hydraulic station.
Frequency control designed for glass transmission.
Output: 800-1000 units-single shift 8 hours (double layer IG, size 1m).
Panel press open able, easy for maintenance.

Model:                          LBZ2500PD            LBZ2500P
Power supply:                   380V/50Hz            380V/50Hz
Total power:                    21.95kW              21.95kW
Cleaning speed:                 0~8m/min             0~8m/min
Working speed:                  15-45m/min           15-45m/min
Min.glass size:                 200×450mm           200×450mm
Max.glass size:                 2200×3000mm         2200×3000mm
Max.Insulating glass thickness: 40mm                 40mm
Glass thickness:                3~12mm               3~12mm
Overall dimension:              22400×2300×3400mm  21400×2100×3100mm
