Adopt Taiwan linear guide rail. the bearing of the lead guide rail is face to face, the long time use precision is high.
High speed drivers, fast speed and great strength.
No dust oiling structure, guarantee the long term running of the mechanical aspect.
Break point and break knife continue engraving function, can engrave at any place as you like.
Strong compatibility: compatible various CAD/CAM software like Type3/artcam/castmate/proe/Corelerow/Wentai.
High power frequency changing water cooled spindle, can process hard materials efficiently.

Spindle power：2.2-4.5KW
Power supply：380V/50HZ
X.Y working area：900×1500mm
Z working area：＞150mm
Table size：1080×2000mm
Max. speed：8m/min
Max. working speed：0-3m/min
Precision：0.005mm
Max. feeding height：＞180mm
Spindle speed：0-24000rpm
Work mode：Stepper
