Features:
Used for processing aluminium profile end step face and end slot etc.
Super precision main shaft insured accurate and steady processing.
Automatic feed, small labor intensity.
Convenient tool setting due to adjustable worktable.
At the same time milling multi-piece profiles. Input power：1.5Kw
Power supply：380V/50Hz
Air pressure：0.5~0.8Mpa
Motor rotary speed：2800r/min
Cutter specification：Φ200×Φ32mm
Cutter adjustment：0-80mm
Milling cutter diameter：Φ110-Φ200mm
Worktable feed stroke：0-320mm
Overall dimension：850×740×1280mm
