Equipment Feature
Applicable for drilling holes,milling grooves,processing circular holes and special-shaped holes,plane engraving of aluminum alloy profile
System adopts Taiwan Syntec CNC Controller
Adopting electric spindle:high precision,high safety and reliablity
X axis adopts high-precision oblique gear and rack;Y and Z axis adopt high-precision ball screw transmission and high precision
By using programming software to automatically transform and process G code;easy operation;high efficiency and low labor intensity.
Worktable can overturn 180°，-90°~0°~+90°；it can realize three-sides processing by clamping one time；it can process deep and special-shaped holes through worktable overturn; high efficiency and precision.

X-axis stroke：1200mm
X-axis feed rate：0~60m/min
X-axis positioning accuracy：±0.05mm
Y-axis stroke：300mm
Y-axis feed rate：0~48m/min
Y-axis positioning accuracy：±0.02mm
Z-axis stroke：280mm
Z-axis feed rate：0~20m/min
Z-axis positioning accuracy：±0.02mm
Repeat location accuracy：±0.02mm
Roughness：Ra 6.3 μm
Spindle Power：3kW
Power Specification：380V/50Hz
Spindle Speed：0~18000rpm
Total Power of Machine：6.5kW
Working Pressure：0.5～0.8MPa
Machine Size：2200×1500×1950mm
Net Weight：610kg
