Main Feature:
Applied to punching processing of single modes and combination modes.
Installation and replacement of mould can be of large,convenient ness,fastness,high speed and high production.
Used advanced and reliable mechanical structure design and solved two big technical diffcult problems of the mould damage and equipment wornness because of imbalance of cutting force.
Using extended the workench,3 position can install 3 moulds,and can work at the same time,greatly improve the working efficiency.

Input Power： 3kw
Power supply： 380V/50Hz
Capability of Oil Box： 50L
Press nominal Pressure：100KN
Travel Times： 30/min
Closing Height： 280-140mm
Punching Travel： 60mm
Overall Dimension： 1300×730×1280mm
